HIT-RE 500 V3 Epoxy anchor
Ultimate-performance injectable epoxy mortar with approvals for rebar connections and heavy-duty anchoring
- Base materials: Concrete (cracked), Concrete (non-cracked)
- Base material condition: Dry, Wet
- Approvals / test reports: ETA, Fire, Seismic
Customers also searched for anchoring structural steel, fast-curing epoxy mortar, anchoring mortar, adhesive mortar or anchoring.
Technical Data
Base materials
Concrete (cracked), Concrete (non-cracked)
Base material condition
Dry, Wet
Approvals / test reports
ETA, Fire, Seismic
Seismic loading
Yes
Fire resistance
Yes
PROFIS software
Yes
Anchoring elements
HAS-U threaded rods, Rebar
Cleaning procedures
Automatic cleaning (SafeSet hollow drill bit), Compressed-air cleaning, Manual cleaning
Storage and transportation temperature range
5 - 25 °C
In-service temperature – range
-40 - 70 °C
Documents
Features & Applications
Features
- High performance and technical superiority as per international approvals
- Suitable for diamond-cored holes – when prepared using the TE-YRT roughening tool
- Injectable epoxy suitable for all-year use – cures at temperatures down to -5°C / 23°F
- Longer working time – allows greater flexibility during installation
- Suitable for water-filled holes and underwater applications (depending on rod specification and approvals)
Applications
- Structural connections with post-installed rebar (e.g. extension/connection to walls, slabs, stairs, columns, foundations, etc.)
- Structural renovation of buildings, bridges and other civil structures, retrofitting and re-strengthening of concrete members possible
- Anchoring structural steel connections (e.g. steel columns, beams, etc.)
- Fastenings requiring seismic qualification
- Fastening in natural stone and wood, including GLT and CLT made by spruce, pine or fir.
For approval or certificate information, please see individual items.
