Semi-automatic powder-actuated tool for fastening single nails in medium-duty applications on both concrete and steel

  • Dimensions (LxWxH): 345 x 50 x 157 mm
  • Weight: 2.4 kg
  • Fastener intake: Single

Customers also searched for nail fastening tooldirect fastening toolformwork toolsdirect fastening or direct fastening.

Technical Data

Dimensions (LxWxH)
345 x 50 x 157 mm
Weight
2.4 kg
Fastener intake
Single
Fastener length range
14 - 62 mm
Cartridge type
.27 calibre short, 6.8/11 M10
Automatic piston return
No
Bluetooth
No
Hilti Connect
Yes
Power (max.)
245 J
Power regulation
No
Piston type
X-P8S-352

Documents

Features & Applications

Features

  • One tool for a wide range of applications
  • Compact, sleek design – allows access to narrow spaces
  • Easy to use and maintain – minimising errors and tool downtime
  • Consistent energy output over entire lifetime – delivering more reliable fastening quality
  • Maximum nail length 62 mm, or 72 mm for wood-to-concrete applications

Applications

  • Fastening formwork or formboard to concrete
  • Fastening sill plates or trusses to concrete
  • Easy to use and maintain – minimising errors and tool downtime
  • Fastening wall-ties to concrete or steel
  • Fastening wire mesh (chicken mesh) to concrete

For approval or certificate information, please see individual items.

Services

Hilti Tool Service

  • Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
  • After the no-cost period, repair costs are capped
  • Product warranty against parts and manufacturing irregularities for as long as we service the tool
  • Product warranty against parts and manufacturing irregularities for 20 years
  • 3-month no-cost period after each paid repair
More information about Tool Services

LifeTime Services

  • No repair costs for 2 years from date of purchase, including parts subject to wear and tear, shipping and labour
  • After the no-cost period, repair costs are capped for as long as we service the tool
  • 3-month no-repair-cost period again after every paid repair
  • Materials and workmanship warranty over the entire life of the tool
  • Pick-up and delivery service
More information about LifeTime Services
